【Features and Functions】
· Generating PDF report without any software and driver
· Build-in USB interface
· LCD shows recording status, readings, limit and alarm information
· 6 mark points supported
· LED status and alarm indication
· Low battery warnings
· Wide measurement range -200~250℃
· User configurable settings
· To save as txt/csv/xls/dlg file
· Password control
· User can re-calibrate
【Specifications and Selection Guide】
Specifications | YMP-10D | YMP-11D | YMP-10(no LCD) | YMP-11(no LCD) | YMP-11LT(no LCD) | YMP-11ED | YMP-700ED |
Use type | Multi-use |
Measuring range | -30~70℃ (Internal probe) | -40~70℃ (Int. ) | -40~125℃ (External probe) | -200~250℃ (Enternal probe) |
Accuracy(typ.) | ±0.5℃ | ±0.3℃(-15.0~70.0℃) ±0.5℃(-30.0~-15.1℃) | ±0.5℃ | ±0.3℃(-15.0~70.0℃) ±0.5℃(-30.0~-15.1℃) | ±0.3℃(-15.0~70.0℃) ±0.5℃(-30.0~-15.1℃) ±0.7℃(-40.0~-30.1℃) | ±0.3℃ | ±0.5℃(-100~100℃) ±1.0℃(others) |
Resolution | 0.1℃ |
Data storage capacity | 30240 |
Sample interval | 10sec. to 18hours |
Typ. battery life | 2.5 years(25℃, 15min. interval) | 2.5 years 25℃, 15min | 2.5 years(25℃, 15min. interval) |
High and low alarm | User configurable |
Alarm delay | 0~960min. |
Alarm type | Single type; Accumulation type |
Start delay | 0~254min. |
Start mode | By button |
Stop mode | By button; Memory full; When into USB |
Operation environment | Same as measuring range | -30~70℃ |
Storage environment | Same as measuring range | -30~70℃ |
Size/Weight/Case material | 75mmX28mmX10mm/20g/ABS |
Protection class | IP40 | IP44 | IP40 |
Standards/Certificates | CE, ROHS,EN12830 |
Communication interface | Build-in USB 2.0 |
Power supply | CR2032 3.0v lithium battery, factory replaceable | 3.6v lithium factory replaceable | CR2032 3.0v lithium battery, factory replaceable | CR2032 3.0v lithium battery, factory replaceable |
Configurable software | PidifiX (windows 7&8&vista&10 32&64bits) |
Warranty | 12 months |
