Meet the requirements of many national standards for medical devices such as the Chinese Pharmacopoeia, the United States Pharmacopeia, the Standard for Pharmaceutical Packaging Materials, and the GB8368-2018 for infusion equipment.
High-performance laser light source and light energy compensation circuit ensure the testing accuracy of various colorless and colored clear samples.
The sampling slit and pipeline are made of imported 316L and PTFE materials, which can directly detect special corrosive solutions such as organic solvents and oil bases, etc.
Automatic lifting system, suitable for inspection of irregular packaging inspection products
High-performance processor and nearly 10,000 counting channels realize high-precision data collection.
Fully automatic calibration improves calibration efficiency and ensures accurate and reliable test data.
The instrument can be calibrated and calibrated according to Chinese Pharmacopoeia, United States Pharmacopoeia, ISO21510 and other standards, and can meet drug import and export testing requirements.
The audit trail function ensures the integrity of electronic data, and the equipment usage information and current detection data can be retrieved at any time.
Multi-level authority management ensures data security and meets the requirements for data audit tracking in computerized systems.
Using Android operating system, humanized interactive experience and simple operation.
Built-in database with massive storage and data statistical analysis function.
RS232 and USB interfaces can be connected to an external computer to store test results and facilitate data classification and retrieval.
Visible dust-proof door design prevents environmental contamination of samples.
Channel settings: Sixty-four particle size channels, thousands of particle sizes can be customized, accuracy 0.1µm
Particle size range: 1～500µm
Counting range: 0～9999999 grains
Injection volume: 0.2～1000ml (accuracy 0.1ml)
Injection volume accuracy: <±0.5%
Injection speed: 5～80ml/min
Counting accuracy: <specified value ±5%
Channel resolution: >95%
Relative standard deviation: RSD<1.5% (standard particles ≥1000 particles/ml)
Limit detection concentration: 18000 capsules/ml
Stirring speed: 0～1000 rpm
Operating temperature: 10～40℃
Power supply: 100-240VAC; 50/60Hz; <80W
Data output: dot matrix printer, RS232 interface, USB storage interface
