Complying with the 2020 version of the Chinese Pharmacopoeia, it has a special testing program for the Pharmacopoeia, which can directly detect the number of insoluble particles in various volumes of injections, sterile powders and concentrated solutions for injections.
Using high-performance laser light source and light energy compensation circuit to ensure the testing accuracy of various colorless and colored clear samples.
Adopting an advanced high-pressure syringe pump sampling system, the sample injection volume can be set by oneself, and the injection speed can be set according to the viscosity of the sample. The injection speed is stable, the precision is high, and it is not affected by the viscosity of the sample.
Equipped with a special test program for small injections, the injection volume can be set according to the labeled filling volume of the injection, and it will be automatically converted into the number of particles per container after the test is completed.
Use a rotary paddle-type frictionless stirrer with adjustable speed to ensure the uniformity of particle distribution in sample containers of different shapes and volumes and improve the accuracy of data.
Adopts large-screen LCD display, humanized Chinese interface settings, powerful functions, and can display multi-channel test data, histograms and other information.
It has the function of presetting drug names and stores hundreds of injection drug names in the "Chinese Pharmacopoeia", making the operation easy and fast.
It has automatic data processing and storage functions; it can be connected to the laboratory operating platform for network management, or it can be directly connected to a computer to use special data analysis software for data analysis and statistics.
Channel settings: ≥2μm, 4~6μm, ≥5μm, ≥8μm, ≥10μm, ≥12μm, ≥25μm, ≥100μm; channels can be customized
Test range: 1~500μm can be selected in sections
Counting range: 0~9999999 grains
Detection concentration: <10000 capsules/ml
Injection volume: 0.2～1000ml; 5ml±0.5%; customized volume
Injection speed: 5～80 ml/min, adjustable
Accuracy: ±10% of specified value
Channel resolution: >95%
Relative standard deviation: RSD<2% (standard particles ≥1000 particles/ml)
Stirring speed: 0～2000 r/min, rotary paddle type adjustable
Working temperature: 10～40℃
Power supply: AC220V±10%; 50Hz; ≤100W
