Operation Principle：
Oxidation organism by UV lamp and convert organic stuff into carbon dioxide, which detection adopted by direct conductivity method. The total organic carbon is the difference of the total carbon (TC)concentration in samples tested after oxidation and not oxidation of the sample total inorganic carbon(TIC), namely: TOC = TC- (TIC).
Parameters：
Power Supply | 100-260VAC 50HZ,120W |
Conductivity Detection Range | 0.055µs/cm-8.000µs/cm |
Measure Range | 0.001mg/L ～ 1mg/L（1 ～ 1000ppb） |
Accuracy | ±3% |
RSD | Repeatability ≤ 3% |
Resolution | 0.001mg/L |
Response Time | 5mins |
Measuring Limit | 0.001 mg/L |
Analyzing Time | Continues Analyzing |
Sample Temperature | 1-99℃ |
Applied Range | Online/Offline/ Cleaning Validation |
Audit trail,Records | ≥ 3years storage |
Authority Management | User name and password login ，to meet FDA 21CFR PART 11 requirements |
Print Function | External Printer |
Data Copy | USB disk to export the data |
Display Screen | Color Touch Screen |
Expansion Por | Ethernet Port 232 Serial Port Power Output Port 4-20MA signal output |
Weight | 8.5KG |
Dimension(mm) | 400*240*270 |
Audit trail | customization |
Main feature：
※ The instrument adopts no pump pipe design, and there is no need to configure the pressure reducing valve device for the online testing;
※ The instrument adopts the latest high-performance CPU processor, to expand the instrument function and improve the processing speed and accuracy
※ The ultra-large capacity of storage space can be used as the real-time query for raw data;
※ Due to no pump pipe design, there is no need of online accessory (pressure reducing valve), to reduce customers' material use, simplify the installation procedure and make flow rate more stable;
※ The independent research and development team can carry out the design of specific solutions according to the needs of customer。
Application：
On line monitoring and laboratory testing of pharmaceutical water (purified water, injection water), and cleaning validation, electronic industry, food industry, etc.
