Feature:
1. P.I.D. environmental scanning micro-processing controller controls temperature accurately and reliable.
2. Optional timing function: up to 6 days. (0 ~ 9999 minutes)
3. Digital LED display of preset & real temperature.
4. Inner glass door can help to reduce the influence to control the chamber deviation.
5. Smooth and corrosion-resistant stainless steel surface with round inner corners makes cleaning work easier.
6. With over-temperature alarm system to ensure equipment safety.
7. Optional RS485 connector / optional built-in printer / optional short messages remote alarm system
8. Applying the water-jacketed system, the temperature is more stable and insusceptible in accidents like power supply cut off.
Specifications:
Model | GNP-9050 | GNP-9080 | GNP-9160 | GNP-9270 |
Capacity | 50 liters | 80 liters | 160 liters | 270 liters |
Internal Dims (WxDxH mm) | 350x350x410 | 400x400x500 | 500x500x650 | 600x600x750 |
External Dims (WxDxH mm) | 510x470x650 | 560x520x740 | 660x620x955 | 760x720x1060 |
Power | 150W | 200W | 250W | 400W |
Control Mode | Microprocessor PID Controller |
Convection | Forced Convection |
Display | LED Display |
Number of Doors | 2 (Built In Heat Proof Glass Door) |
Temperature Range | Ambient Temp. +5 ~ 65℃ |
Display resolution | ± 0.1 ℃ |
Temperature Fluctuation | ± 0.5 ℃ |
Sensor | PT100 |
Material Internal | Stainless Steel |
Material External | Steel Plate With Powder Coating |
Door Gasket | High Temperature Silicone Rubber |
Shelves | 2 Adjustable Position Shelves |
Safety | High temperature safety cutoff with audio/visual alarm, over current glass fuse |
Voltage | 220V 50Hz |
