★Optical control technology is used to realize the automatic detection of seal printing.
★At 7 "color LCD touch screen, graphical operation interface, Chinese and English with symbol display, built-in clock and parameter setting, automatic storage function;"
★The sealing counter can realize the counting statistics of ascending and descending order within 0-9999;
★The function of adjusting printing margin, printing interval symbol and printing interval distance;
★Microcomputer intelligent temperature control, temperature deviation less than 1%, working temperature 60-220 ℃ arbitrary setting, preset 90 ℃, 120 ℃, 180 ℃, 220 ℃ four modes, convenient and rapid setting of the required temperature;
★Rapid heating design, room temperature rises to 180 ℃ less than 40 seconds, high efficiency and energy saving, to meet the needs of fast-paced work;
★Auxiliary cooling design, designed with temperature linkage exhaust cooling system, reduce the waiting time of temperature conversion from high temperature sealing to low temperature sealing;
★The utility model adopts the floating type constant pressure pressing system design, which is suitable for sealing the paper plastic bag, the paper plastic solid bag and the paper bag.
★Advanced flat heating element, can dry burn, high temperature resistance, long life, high thermal efficiency;
★Automatic energy-saving standby function, standby time adjustable, intelligent standby recovery, high-speed recovery of working temperature, can extend the service life of equipment, reduce energy consumption;
★When the sealing temperature exceeds the limit deviation of the set working temperature, the equipment will stop working automatically and give an alarm or prompt to ensure the sealing effect and the safety of the equipment.
★It can print sterilization time, temperature, speed, pressure, sealing time, operator, equipment number and other parameters that need to be recorded, which is convenient for inspection and archiving. It is equipped with sealing detection mode, which can be tested in this mode, and can print sterilization time, temperature, speed, pressure, sealing time, operator, equipment number and so on. Meet the packing requirements of health industry standards
Printing system：
★In Chinese, English and numerals, as well as in accordance with special symbol printing functions such as "YY 0466-2003 symbols for the labelling, marking and provision of information for medical devices", The printing requirements of sterilizing date, expiration date, sterilizing batch, operator, steel number, article name and so on required by the Ministry of Health can be realized.
★The contents of operator, article name, pot number, pot number and custom can be preset 12 items and stored for later change and selection.
★The sterilizing date and invalidation period can be adjusted automatically according to the setting, and the monthly days need not be adjusted manually.
★A built-in printer, can not set print items, adjust the print content;
★Fault automatic alarm indicator, can realize the automatic detection of the working process, the emergence of a variety of fault automatic alarm or prompt;
★The print font width can be adjusted to facilitate the printing of more content to a relatively narrow paper bag;
★The print function can be turned off or an entry can be closed as needed;
★The printing content of the paper bag is intelligently matched with the width of the paper bag, and the system will give the requirement of the width of the paper bag according to the selection of the printed content, assist the operator to determine the printed content or select the suitable paper bag, and report a reminder when the width of the paper bag is insufficient.
★It is easy to operate and is the first in China to change the ribbon on the side.
Echnical Data：
Control system： 7 "color LCD touch screen
Seal speed： 10m/min
Seal width： 12mm
Seal left side： 0~35mm adjustable
Sealing strength： meet the requirements of YY/T 0698.5-2009.
Shell material： carbon steel spray or 304 stainless steel
AC power： 220V 50Hz
Maximum power： 500W
Equipment size： 560x 260x220 (mm)
Weight： 18kg
